26/35kV 3 Core Copper Wire Medium Voltage Power Cables
CU/XLPE/STA/PVC Electrical Cable Steel Tape Armored
Information
| number of cores | 1, 2, 3, 3+1, 3+2, 3+3, 4, 4+1, 4+2, 5 andn so on. |
| Conductor | Solid or stranded copper |
| Insulation | Cross-linked polyethylene (XLPE) or Polyvinyl chloride (PVC) |
| Filler | Polypropylene filament with lapped binding tape |
| Binder | Binding tape |
| inner sheath | Polyvinyl chloride (PVC) |
| Amour | Galvanized steel wire armored(SWA) or steel tape armored(STA) |
| Over Sheath | Polyvinyl chloride (PVC) |
Nominal Section
Area(mm2) :1.5 2.5 4 6 10 16 25 35 50 70 95 120 150 185 240 300 400
500 630 800
Features
XLPE insulated power cable do not has excellent electric,
mechanical properties,but also has powerful resistance against
chemical corrosion,heat resistance and enviromental stress
resistance. Its structure is simple. The long period operating
temperature is +90 °C. It is conveninet to use and can be laid with
no restriction of different level.
XLPE insulated steel wire armoured power cable: XLPE/PVC insulated
power cable has a number of advantages over paper insulated and PVC
insulated cable. XLPE cable has high electric strength, mechanical
strength, high-ageing resisting, environmetal stress resisting
antichemical corrossion, and it is simple construction, using
convenient and higher operating of long term temperature. It can be
laid with no drop restriction.
Various of flame-retardant and non-flame retardant XLPE cable can
be manufactured with three technology(peroxide, silane and
irradiation crosslinking). The flame-retardant cable covers all
kinds of low-smoke low-halogen low-smoke halogen free, and
non-smoke nonhalogented and three classes of
A, B, C.
The Rated Voltage(kv):
1st class 0.6/1 1.8/3 3.6/6 6/10 8.7/15 12/20 18/30 21/35
2nd class 1/1 3/3 6/6 8.7/10 12/15 18/20 - 26/35
Application:
1) These cables are most suitable for direct burial or for
installation on trays or ducts, Where there is
a risk of mechanical damage, armoured cables should be used.
2) For laying in ground along route with large difference of level
able to bear external mechanical forces.
CCV Line
Testing process
FAQ
* How to assure the quality of products?
1. Most of our products have certification.
2. Our Lab staff will test the material and check the process card
before production.
3. The O.D tester is testing all the time during production, and
the production line is always under control.
4. The product will be tested by Lab staff after production.
* Do you offer free samples or not?
1. If we have inventory about the sample you need and the total
amount is not large, it's free.
2. If we don't have inventory, according to our company's rule,
sample and freight costs need to be paid by your esteemed company.
And we will return the sample cost to you when you place the first
order with us. Thanks for your support.
* When I want customized products, how to do it?
We have professional equipment, technicians & skilled employees,
OEM & customized service is welcome. Drawings or samples are
required. Of course, the purchased quantity should meet our MOQ.
